Champion Twin Arm Underbody Subframe Hoists

CHAMPION Uninstalled Twin Arm Underbody Subframe Hoist for Contractor Bodies

Champion offers several models of direct mount hoists. Direct mount, also known as "pusher type" hoists mount directly to the body and have few moving parts. Champion direct mount hoists are ideal for light to medium duty applications. Champion manufacturers all direct mount hoist components including cylinders. These hoists are available for 8' to 14' body applications with dumping capacities ranging from 7.7 to 15.8 tons. Champion manufactures direct mount hoists using mill certified 50K and 100K steel and encapsulates them in a super durable abrasive and chemical resistant thermoset powder coating. All hoists feature integrated Zerk grease fittings at all pivots. When you purchase a direct mount hoist from Champion, all necessary mounting hardware, fasteners, and body prop hardware are included. All champion hoists are covered under a 3-year factory warranty.

IMPORTANT INFORMATION:

FF hoist will include the subframe, cylinder, torque arm, 2-lift arms & pins, safety prop, and cup, rear hinges, and decals

EMSA kits will include all of the above with the FF hoist PLUS Bucher single acting electric pump, hoses, fittings, and push-button controls w/cord

EMDA kits will include all of the above with the FF hoist PLUS Bucher double-acting electric pump, hoses, fittings, and push-button controls w/cord

P21-8C kits will include all of the above with the FF hoist PLUS P21 gear pump, Champion cable operated tank/valve, hoses, fittings, and cable controls

P21-8S kits will include all of the above with the FF hoist PLUS P21 gear pump, Champion solenoid-operated tank/valve, hoses, fittings, and push-button controls

P22-8C kits will include all of the above with the FF hoist PLUS P22 gear pump, Champion cable operated tank/valve, hoses, fittings, and cable controls

P22-8S kits will include all of the above with the FF hoist PLUS P22 gear pump, Champion solenoid-operated tank/valve, hoses, fittings, and Push Button Controls

P22-V20-4 DOUBLE ACTING kits will include all of the above with the FF hoist PLUS P22 gear pump, remote valve, tank, hoses, fittings, and cable controls

Showing 1 - 15 of 15 results
