BOSS VBS15310C – VBX9000 3 Cubic Yard Pintle Chain Spreader
| Capacity | cubic yd 3 / cubic m 2.3 |
| Control | Dual Variable Speed Control |
| Deflector | Standard |
| Display Type | LCD Display Controller |
| Feed Mechanism | Pintle/Conveyor Chain |
| Feed Motor | 3/4 HP SS Feed Motor |
| Gearbox | Planetary Worm 137:1 |
| Hopper Construction | 3/16” (0.5 cm) Double Wall Polyethylene Hopper |
| Hopper Cover | VCP Tarp w/ integral tie-downs |
| Hopper Height | 49 in / 124.46 cm |
| Hopper Length | 107 in / 272 cm |
| Hopper Width | 48 in / 121.92 cm |
| Inverted V-Baffle | Optional |
| LED CHSML | Standard |
| Lighting | Dual 55 watt halogen variable output work lights (Standard) – dual LED work lights (optional) |
| Material Conveying Method | 14” (36 cm) Wide Pintle Chain |
| Max Feed Rate | 4 cu ft (0.11 cu m) per minute |
| Minimum Bed Length | 96 in (243.8 cm) |
| Spinner | 14.5 in (36.8 cm) Diameter Poly Spinner |
| Spinner Assembly | Easily Removable/Swing Out and Height Adjustable |
| Spinner Gearmotor | 1/8 HP Spinner Gearmotor (Located above spinner) |
| Spreader Overall Length | 122 in / 309 cm |
| Spreading Width | 2 ft – 40 ft (0.6 m – 12 m) Dry free-flowing material |
| Tie-Down Kit | Standard |
| Top Screen | Standard |
| Trough | 11 ga. Stainless Steel |
| Vehicle Application | 15 000+ GVWR |
| Vibrator | Optional |
| Weight | 760 lbs / 345 kg |
The BOSS VBX9000 pintle system constructed with the versatility to spread various types of material maximizes productivity and minimizes what you want least – ice and snow. Utilizing up to three cubic yards of de-icing capacity the VBX9000 is your heavy-duty solution for heavy-duty jobs. BOSS VBX spreaders are backed by quality durability and service BOSS has built its reputation on.
