Maxon BMR (Oct 2014 - Sep 2016) Left Hand Runner Assembly Diagram From ITEParts.com

ID	Title	SKU	Price
1	Maxon 288790-01 - Extension Plate Weldment BMR Weld-On ST	288790-01-MAXO	$371.52
1	Maxon 288790-111 - Extension Plate Weldment BMRW Weld-On SST	288790-111-MAXO	$861.21
1	Maxon 288790-11G - Extension Plate Weldment BMRW Weld-On ST G	288790-11G-MAXO	$342.66
1	Maxon 288790-31-500 - Extension Plate Weldment BMRW Bolt-On ST PRIMER	288790-31-500-MAXO	$379.70
2	Maxon 286290-01 - Plate Weldment Unit Mount	286290-01-MAXO	$498.51
2	Maxon 286290-11 - Plate Weldment Unit Mount SST	286290-11-MAXO	$1,088.06
2	Maxon 286290-21 - Plate Weldment Unit Mount Primer	286290-21-MAXO	$658.05
3	Maxon 901615-03 - Bolt Hex Flange .63-11 X 1.75 Inch LG	901615-03-MAXO	$2.88
4	Maxon 902013-15 - Flat Washer 5/8 Inch ZC	902013-15-MAXO	$0.44
5	Maxon 901023-04 - Flange Lock Nut 63-11 ZC	901023-04-MAXO	$1.82
6	Maxon 903159-01 - Nut Nylon INSTR Stop 1-8 GR8 ZC	903159-01-MAXO	$2.90
7	Maxon 905381-01 - Screw Spec Hex Cap Full THD .63-11 X 4 ZC	905381-01-MAXO	$5.57
8	Maxon 286295-01 - Gusset	286295-01-MAXO	$23.40

INCLUDE MODEL AND SERIAL NUMBER WHEN ORDERING! TO HELP YOU IDENTIFY THE DATE RANGE:

LOCATE YOUR SERIAL PLATE on your Liftgate.
LOOK FOR THE ‘SERIAL #’ FIELD and identify the first four digits.
IF your Liftgate was manufactured BEFORE JUNE 2014, your plate will show the Month then the Year.
IF your Liftgate was manufactured AFTER JUNE 2014, your plate will show the Year then the Month.
