Maxon BMR (Oct 2018 - Present) Left Hand Chain Assembly Diagram From ITEParts.com

ID	Title	SKU	Price
0	Maxon 299194-669MG - F/O Assembly AL 85 X 30+12 DCS MG BMR	299194-669MG-MAXO	$3,083.93
1	Maxon 287591-01 - Flat AL Bumper Holder	287591-01-MAXO	$13.55
2	Maxon 900001-4 - Screw BUT 5/16-18 X 1-1/4 Inch Alloy	900001-4-MAXO	$1.97
3	Maxon 901001 - Nut - Nylon - 5/16-18 Zinc	901001-MAXO	$0.18
4	Maxon 902013-10 - Washer Flat 5/16 Inch SAE ZC	902013-10-MAXO	$0.18
6	Maxon 907362-01 - Flashing Safety Light	907362-01-MAXO	$96.99
7	Maxon 900719-08 - Button Screw .25-20 X 1.25 Inch SS	900719-08-MAXO	$0.51
8	Maxon 225278-02 - Rubber Bumper 3/4 x 1.5 x 5 - 2 Hole	225278-02-MAXO	$24.86
12	Maxon 287443-15 - 42.38 Inch Cart Stop Pin	287443-15-MAXO	$35.73
13	Maxon 900722-03 - Screw BTN 10-24 X.5 SS	900722-03-MAXO	$0.14
14	Maxon 282729-01 - Spring C/S .08 Wire 302 SS	282729-01-MAXO	$12.39
15	Maxon 297068-06 - Cart Stop Assembly DCS 41.29 Inch LG LH	297068-06-MAXO	$247.16
16	Maxon 297068-05 - Cart Stop Assembly DCS 41.29 Inch LG RH	297068-05-MAXO	$226.67

INCLUDE MODEL AND SERIAL NUMBER WHEN ORDERING! TO HELP YOU IDENTIFY THE DATE RANGE:

LOCATE YOUR SERIAL PLATE on your Liftgate.
LOOK FOR THE ‘SERIAL #’ FIELD and identify the first four digits.
IF your Liftgate was manufactured BEFORE JUNE 2014, your plate will show the Month then the Year.
IF your Liftgate was manufactured AFTER JUNE 2014, your plate will show the Year then the Month.
