Maxon DMD (Nov 2012 - Jul 2018) Hydraulic Components Equipped With Power Closer Diagram

Maxon DMD (Nov 2012 – Jul 2018) Hydraulic Components Equipped With Power Closer Diagram

SKU: DMD-NOV12-JUL18-HYDC-EWPC-DG Category:
ID Image Title SKU Price Quantity Add to Cart
1Maxon 906761-01 - Connector OR #4 OR #6 M-FMaxon 906761-01 - Connector OR #4 OR #6 M-F906761-01-MAXO$11.10
2Maxon 903409-03 - Washer - FEND .41 X .88 Inch OD SSMaxon 903409-03 - Washer - FEND .41 X .88 Inch OD SS903409-03-MAXO$0.14
3Maxon 902019-5 - Washer Lock S/ST .680 OD X .385 ID InchMaxon 902019-5 - Washer Lock S/ST .680 OD X .385 ID Inch902019-5-MAXO$0.45
5Maxon 287856-01 - Master Cylinder 1.50 X 52.31 X .63Maxon 287856-01 - Master Cylinder 1.50 X 52.31 X .63287856-01-MAXO$2,344.88
6Maxon 905158 - Elbow Straight F/S#-O-R #6Maxon 905158 - Elbow Straight F/S#-O-R #6905158-MAXO$69.20
7Maxon 906704-02 - Elbow NPSC SAE #6 F/S O-R M-MMaxon 906704-02 - Elbow NPSC SAE #6 F/S O-R M-M906704-02-MAXO$52.47
8Maxon 5-30036 - 12V Logic ValveMaxon 5-30036 - 12V Logic Valve5-30036-MAXO$195.32
9Maxon 906717-02 - Flow Control Valve 1.5 GPMMaxon 906717-02 - Flow Control Valve 1.5 GPM906717-02-MAXO$112.17
10Maxon 286440-01 - F/S Tube Assembly 63.38 Inch LGMaxon 286440-01 - F/S Tube Assembly 63.38 Inch LG286440-01-MAXO$51.39
11Maxon 286437-01 - F/S Tube Assembly Column RHMaxon 286437-01 - F/S Tube Assembly Column RH286437-01-MAXO$92.06
12Maxon 283212-05 - Return Line Assembly LH CLMNMaxon 283212-05 - Return Line Assembly LH CLMN283212-05-MAXO$53.84
13Maxon 283190SK-02 - Seal Kit Slave CYLMaxon 283190SK-02 - Seal Kit Slave CYL283190SK-02-MAXO$77.85
16Maxon 287219-02 - H/C F/S Tube Assembly 27.28 Inch LGMaxon 287219-02 - H/C F/S Tube Assembly 27.28 Inch LG287219-02-MAXO$35.28
18Maxon 906712-03 - Tube End O-Ring #8 1/2 ORFSMaxon 906712-03 - Tube End O-Ring #8 1/2 ORFS906712-03-MAXO$1.39
19Maxon 906827-01 - Elbow 45 STR ORFS/ORB #8M #6Maxon 906827-01 - Elbow 45 STR ORFS/ORB #8M #6906827-01-MAXO$7.85
20Maxon 905173 - Connector F/S#6 and O-R#6 M-MMaxon 905173 - Connector F/S#6 and O-R#6 M-M905173-MAXO$3.51
22Maxon 906864-01 - Hex Head Plug M20X1.5 THRDMaxon 906864-01 - Hex Head Plug M20X1.5 THRD906864-01-MAXO$12.87
23Maxon 905162 - Elbow Bulkhead Union F/S #6Maxon 905162 - Elbow Bulkhead Union F/S #6905162-MAXO$38.60
24Maxon 906712-02 - Tube End O-Ring #6 3/8 ORFSMaxon 906712-02 - Tube End O-Ring #6 3/8 ORFS906712-02-MAXO$1.30
25Maxon 283555-01 - P/F Opener CYL AssemblyMaxon 283555-01 - P/F Opener CYL Assembly283555-01-MAXO$919.49
25Maxon 283555SK-01 - Seal KitMaxon 283555SK-01 - Seal Kit283555SK-01-MAXO$245.43
26Maxon 906759-01 - Connector #6FS #4OR M-MMaxon 906759-01 - Connector #6FS #4OR M-M906759-01-MAXO$16.14
27Maxon 286439-01 - F/S Tube Assembly Return Line RHMaxon 286439-01 - F/S Tube Assembly Return Line RH286439-01-MAXO$87.41
28Maxon 283538-01 - Hose Assembly 46 Inch LGMaxon 283538-01 - Hose Assembly 46 Inch LG283538-01-MAXO$64.74
29Maxon 283193-02 - 1/2 ORFS Flange SealMaxon 283193-02 - 1/2 ORFS Flange Seal283193-02-MAXO$3.50

INCLUDE MODEL AND SERIAL NUMBER WHEN ORDERING! TO HELP YOU IDENTIFY THE DATE RANGE:

  1. LOCATE YOUR SERIAL PLATE on your Liftgate.
  2. LOOK FOR THE ‘SERIAL #’ FIELD and identify the first four digits.
  3. IF your Liftgate was manufactured BEFORE JUNE 2014, your plate will show the Month then the Year.
  4. IF your Liftgate was manufactured AFTER JUNE 2014, your plate will show the Year then the Month.

INCLUDE MODEL AND SERIAL NUMBER WHEN ORDERING!

DUE TO PRODUCTION AND SHIPPING RESTRICTIONS, THERE IS AN $80.00 MINIMUM ORDER REQUIREMENT FOR MAXON PARTS. THIS TOTAL DOES NOT INCLUDE PARTS ORDERED FROM OTHER MANUFACTURERS!
