Maxon GPTWR (Jan 2014 - Mar 2015) Low-Voltage Thermal Switch Diagram From ITEParts.com

ID	Title	SKU	Price
1	Maxon 283128-02-501 - EXT PL Weldment GPTWR 102 LG	283128-02-501-MAXO	$1,300.65
2	Maxon 900745-04 - Screw Soc FL .5-13 X 1.5 Inch	900745-04-MAXO	$3.69
3	Maxon 267708-01 - Nylon Bumper	267708-01-MAXO	$24.17
4	Maxon 282257-01 - Latch Walk Ramp	282257-01-MAXO	$33.23
5	Maxon 282258-01 - Spring W/Ramp Latch	282258-01-MAXO	$17.31
6	Maxon 900014-1 - Screw Hex Cap .38-16 X 1.38 G8 ZC	900014-1-MAXO	$0.80
7	Maxon 900014-15 - Screw Hex Cap .38-16 X 4.5 G8 ZC	900014-15-MAXO	$3.17
8	Maxon 901001 - Nut - Nylon - 5/16-18 Zinc	901001-MAXO	$0.18
9	Maxon 901002 - Nut Nylon 3/8-16 Zinc	901002-MAXO	$0.36
10	Maxon 902000-8 - Flat Washer - .312 .063 THK	902000-8-MAXO	$0.32
11	Maxon 902000-10 - Washer Flat .375 X .063 THK	902000-10-MAXO	$0.36
12	Maxon 908094-01 - BRG Flange .38 ID X .38 LG	908094-01-MAXO	$1.74
13	Maxon 900021-9 - Screw SOC .312-18 X 2-1/2 FL	900021-9-MAXO	$0.95
14	Maxon 282346-01G - Flat Galvanized	282346-01G-MAXO	$13.46
14	Maxon 282346-01 - Flat	282346-01-MAXO	$10.22
15	Maxon 282348-01 - Flat Spacer	282348-01-MAXO	$8.33
16	Maxon 282347-01 - Walk-In Ramp Pad	282347-01-MAXO	$22.11
17	Maxon 282344-01G - Stopper 1.5 DIA X 1.25 LG GALV	282344-01G-MAXO	$29.78
17	Maxon 282344-01 - Stopper	282344-01-MAXO	$21.72
18	Maxon 901010 - Nylon Lock Nut 1/2-13 ZC	901010-MAXO	$0.54
19	Maxon 266705-01 - Plate Maxon - 3.25 X 15 BLK	266705-01-MAXO	$3.00
20	Maxon 207644-01 - Rivet BLND .19 X .45 Inch Dome	207644-01-MAXO	$0.18

INCLUDE MODEL AND SERIAL NUMBER WHEN ORDERING! TO HELP YOU IDENTIFY THE DATE RANGE:

LOCATE YOUR SERIAL PLATE on your Liftgate.
LOOK FOR THE ‘SERIAL #’ FIELD and identify the first four digits.
IF your Liftgate was manufactured BEFORE JUNE 2014, your plate will show the Month then the Year.
IF your Liftgate was manufactured AFTER JUNE 2014, your plate will show the Year then the Month.
