Maxon TE-25 (Mar 2013 - Apr 2017) Pump Cover And Mounting Plate Assembly Diagram From ITEParts.com

ID	Title	SKU	Price
1	Maxon 269526-01 - Box Modified with Holes	269526-01-MAXO	$393.00
2	Maxon 908022-03 - Plug Flexible .393 X .471 Inch	908022-03-MAXO	$2.13
3	Maxon 908022-08 - Plug Flexible 1.063 X .63 Inch	908022-08-MAXO	$3.36
4	Maxon 908022-07 - Plug Flexible .275 X .511 Inch	908022-07-MAXO	$1.49
5	Maxon 266428-02 - Grommet 1.0 DIAPH .25 Hole	266428-02-MAXO	$3.42
6	Maxon 269558-01 - Box Cover Modify with Holes	269558-01-MAXO	$94.34
7	Maxon 908193-01 - Rubber Latch	908193-01-MAXO	$12.72
8	Maxon 908194-01 - Fastening Knob	908194-01-MAXO	$1.16
9	Maxon 285884-01 - Battery Box Hinge SS	285884-01-MAXO	$29.85
10	Maxon 903715-03 - Rivet BL/DM AL/AL .25 X .25-.37	903715-03-MAXO	$0.32
11	Maxon 903438-01 - Washer Fender .250 X .875 X .047 Inch THK ZC	903438-01-MAXO	$0.24
12	Maxon 908022-05 - Flexible Plug .580 X .571 Inch	908022-05-MAXO	$3.38
13	Maxon 900719-07 - Screw Button .25-20 X 1 Inch SS	900719-07-MAXO	$0.32
14	Maxon 903137-01 - Nut - Nylon Insert Stop - .25-20 SS	903137-01-MAXO	$0.48

INCLUDE MODEL AND SERIAL NUMBER WHEN ORDERING! TO HELP YOU IDENTIFY THE DATE RANGE:

LOCATE YOUR SERIAL PLATE on your Liftgate.
LOOK FOR THE ‘SERIAL #’ FIELD and identify the first four digits.
IF your Liftgate was manufactured BEFORE JUNE 2014, your plate will show the Month then the Year.
IF your Liftgate was manufactured AFTER JUNE 2014, your plate will show the Year then the Month.
