- Compact, cost-effective power for snow plow lift and angle operations.
- Includes everything you need to power the job.
- Unit contains two independent circuits: 3 way for plow hoist; 4 way for power angle.
- Easy fingertip controls.
- Crossover relief valve protects cylinder and blade should the plow strike a hidden object.
The 4 Way/3 Way DC Power Unit – Electric Controls from Buyers Products is an all-in-one, compact power pack. This horizontal-mount power unit is ideal for powering snow plow lift and angle operations. It includes pre-wired rocker switch controls that provide 4-way/3-position fingertip control for Power Up/Hold/Gravity Down (plow hoist), and 4-way for exact left-right angling of the blade. A crossover relief valve protects the angle cylinder and the plow blade should the plow strike a hidden object.
| Manual Or Push Button | Push Button |
| Mounting Position | Horizontal |
| Reservoir Material | Carbon Steel |
| Motor Horsepower | 2 HP |
| Reservoir Volume | 0.83 Gal |
| Pressure Rating | 2000 PSI |
| Motor Voltage | 12 VDC |
| Width | 6 Inches |
| Length | 17.38 Inches |
| Height | 13.81 Inches |
| Spool Action | Power Up/Gravity Down | Power Up/Power Down |
| Number Of Cartridge Valves | 4 |
| Outlet Port Size | 1/4 NPT |
| Controller Included (Y/N) | Yes |
| Control Cable Length | 72 Inches |
| Motor Power (KW) | 1.5 Kw |
| Min Order Qty | 1 |
| Multiple Sale Qty | 1 |
| Product Code | 636 |
| Sell Pack Type | Box |
| Shipping Weight | 42 Lbs |
| UPC | 724920118736 |
Product Common Use: Snow Plows
