Maxon RCT (Oct 2012 - Present) 1-Piece Platforms With CAM Type Closer Diagram From ITEParts.com

ID	Title	SKU	Price
1	Maxon 202141 - Elbow Brass 1/4 X 1/8 Inch	202141-MAXO	$7.37
2	Maxon 224370-11 - Hose Plastic X 87 Inch LG	224370-11-MAXO	$20.01
3	Maxon 251739 - Valve Flow CONT PRES COMP 2GPM	251739-MAXO	$100.32
4	Maxon 228151 - Swivel 3/8F-3/8M STR	228151-MAXO	$12.11
5	Maxon 226948-18 - Hose Assembly HP 3/8 X 47-1/2 Inch LG	226948-18-MAXO	$55.26
6	Maxon 252002 - Cylinder 2 Bore -28 Stroke RCM	252002-MAXO	$796.95
7	Maxon 228950 - Elbow 3/8F-3/8F 90DEG S	228950-MAXO	$18.71
9	Maxon 202406 - Elbow Brass - 1/4 X 1/4 Inch	202406-MAXO	$17.46
10	Maxon 800183 - Bushing 3/8 X 1/4 Inch	800183-MAXO	$8.48
11	Maxon 906714-01 - Adapter Cap BRS 3/8 NPT FEM THD	906714-01-MAXO	$16.82

INCLUDE MODEL AND SERIAL NUMBER WHEN ORDERING! TO HELP YOU IDENTIFY THE DATE RANGE:

LOCATE YOUR SERIAL PLATE on your Liftgate.
LOOK FOR THE ‘SERIAL #’ FIELD and identify the first four digits.
IF your Liftgate was manufactured BEFORE JUNE 2014, your plate will show the Month then the Year.
IF your Liftgate was manufactured AFTER JUNE 2014, your plate will show the Year then the Month.
