Tommy Gate Railgate Series RTC Diagram (1 OF 2) [Step Van]

Tommy Gate Railgate Series RTC Diagram (1 OF 2) [Step Van]

SKU: TG-RGSRTC-SV-DG1 Category: Brand:
ID Image Title SKU Price Quantity Add to Cart
3Tommy Gate 12627 - Replacement Latch FlipperTommy Gate 12627 - Replacement Latch Flipper12627-TOMM$73.56
3Tommy Gate 13823 - Replacement Self Close Latch FlipperTommy Gate 13823 - Replacement Self Close Latch Flipper13823-TOMM$19.85
4Tommy Gate 1111 - License Plate Mount KitTommy Gate 1111 - License Plate Mount Kit1111-TOMM$6.30
8Tommy Gate 4191 - 13 Tooth Replacement Sprocket - Pin and Keeper (All Aluminum)Tommy Gate 4191 - 13 Tooth Replacement Sprocket - Pin and Keeper (All Aluminum)4191-TOMM$89.63
10Tommy Gate 904 - Replacement Red LED Light with GrommetTommy Gate 904 - Replacement Red LED Light with Grommet904-TOMM$80.01
11Tommy Gate 889 - Replacement Clear LED Light with GrommetTommy Gate 889 - Replacement Clear LED Light with Grommet889-TOMM$83.79
12Tommy Gate 13554 - Replacement LED License Plate LightTommy Gate 13554 - Replacement LED License Plate Light13554-TOMM$39.69
13Tommy Gate 13103 - Replacement Box Cover (89)TX with Alarm and Lights(TA) (SPEC GATE ONLY)Tommy Gate 13103 - Replacement Box Cover (89)TX with Alarm and Lights(TA) (SPEC GATE ONLY)13103-TOMM$978.08
13Tommy Gate 13555 - Replacement Box Cover (89)TX with Lights(TA) (SPEC GATE ONLY)Tommy Gate 13555 - Replacement Box Cover (89)TX with Lights(TA) (SPEC GATE ONLY)13555-TOMM$866.25
13Tommy Gate 13556 - Replacement Self Close Box Cover (89)TX with Alarm and LightsTommy Gate 13556 - Replacement Self Close Box Cover (89)TX with Alarm and Lights13556-TOMM$978.08
13Tommy Gate 13557 - Replacement Self Close Box Cover (89)TX with LightsTommy Gate 13557 - Replacement Self Close Box Cover (89)TX with Lights13557-TOMM$866.25
13Tommy Gate 13824 - Replacement Self Close Box Cover (85) with AlarmTommy Gate 13824 - Replacement Self Close Box Cover (85) with Alarm13824-TOMM$951.30
14Tommy Gate 12628 - Replacement Latch Pin and LanyardTommy Gate 12628 - Replacement Latch Pin and Lanyard12628-TOMM$17.49
15Tommy Gate 12624 - Replacement PS LatchTommy Gate 12624 - Replacement PS Latch12624-TOMM$196.88
15Tommy Gate 13825 - Replacement PS Self Close Latch (TX)Tommy Gate 13825 - Replacement PS Self Close Latch (TX)13825-TOMM$201.60
16Tommy Gate 12625 - Replacement DS LatchTommy Gate 12625 - Replacement DS Latch12625-TOMM$155.30
17Tommy Gate 13558 - Replacement Raise Solenoid-4 PostTommy Gate 13558 - Replacement Raise Solenoid-4 Post13558-TOMM$85.68
19Tommy Gate 13559 - Replacement Compact Fixed ControlTommy Gate 13559 - Replacement Compact Fixed Control13559-TOMM$329.18
20Tommy Gate 13267 - Replacement Auxiliary Hand Pump and Motor 2600psi (2000#TX)Tommy Gate 13267 - Replacement Auxiliary Hand Pump and Motor 2600psi (2000#TX)13267-TOMM$1,234.80
20Tommy Gate 13268 - M319 Replacement Pump and Motor (2100psi) 3qt. 3-Post (1600#TX)Tommy Gate 13268 - M319 Replacement Pump and Motor (2100psi) 3qt. 3-Post (1600#TX)13268-TOMM$730.80
20Tommy Gate 13269 - M319 Replacement Pump and Motor (2100psi) 3qt. 4-Post (1600#TX)Tommy Gate 13269 - M319 Replacement Pump and Motor (2100psi) 3qt. 4-Post (1600#TX)13269-TOMM$730.80
20Tommy Gate 4290 - M319 Replacement Pump and Motor (2600psi) 3qt.(2000#TX)Tommy Gate 4290 - M319 Replacement Pump and Motor (2600psi) 3qt.(2000#TX)4290-TOMM$767.03
21Tommy Gate 989 - Replacement Vent PlugTommy Gate 989 - Replacement Vent Plug989-TOMM$6.30
23Tommy Gate 4355 - Replacement Plastic Tank (3qt.)**Tommy Gate 4355 - Replacement Plastic Tank (3qt.)**4355-TOMM$95.76
24Tommy Gate 958 - Replacement 12V Motor (MOTOR ONLY)Tommy Gate 958 - Replacement 12V Motor (MOTOR ONLY)958-TOMM$441.00
25Tommy Gate 11803 - Replacement 2 Ga. 2 Wire Electric Cable with Lugs-33 ft.Tommy Gate 11803 - Replacement 2 Ga. 2 Wire Electric Cable with Lugs-33 ft.11803-TOMM$406.35
25Tommy Gate 13560 - Replacement 2 Ga. Single Wire Cables with Lugs-35 ft. Red/30 ft. BlackTommy Gate 13560 - Replacement 2 Ga. Single Wire Cables with Lugs-35 ft. Red/30 ft. Black13560-TOMM$384.30
26Tommy Gate 992 - Replacement Copper LugTommy Gate 992 - Replacement Copper Lug992-TOMM$6.30
27Tommy Gate 9760 - Replacement Railgate Cylinder (79-95)Tommy Gate 9760 - Replacement Railgate Cylinder (79-95)9760-TOMM$615.83
28Tommy Gate 8179 - Replacement Rail Cylinder Pin and Keeper (Alum)Tommy Gate 8179 - Replacement Rail Cylinder Pin and Keeper (Alum)8179-TOMM$52.46
30Tommy Gate 973 - Replacement Check ValveTommy Gate 973 - Replacement Check Valve973-TOMM$44.27
31Tommy Gate 12607 - Replacement 9/16 x 9/16 x 90 Degree Steel Cylinder ElbowTommy Gate 12607 - Replacement 9/16 x 9/16 x 90 Degree Steel Cylinder Elbow12607-TOMM$15.60
32Tommy Gate 12966 - Replacement 9/16 Inch x 7/16 Inch Flow ControlTommy Gate 12966 - Replacement 9/16 Inch x 7/16 Inch Flow Control12966-TOMM$75.60
33Tommy Gate 3221 - Cylinder Shaft with Sprockets Assembly (Rail) Includes: Cylinder Repair KitTommy Gate 3221 - Cylinder Shaft with Sprockets Assembly (Rail) Includes: Cylinder Repair Kit3221-TOMM$567.00
34Tommy Gate 3257 - 2 Inch x 35 Inch Replacement Cylinder Barrel (Rail) Includes: Cylinder Repair KitTommy Gate 3257 - 2 Inch x 35 Inch Replacement Cylinder Barrel (Rail) Includes: Cylinder Repair Kit3257-TOMM$442.58
35Tommy Gate 6835 - Replacement Cylinder Clamp (All Aluminum Rail)Tommy Gate 6835 - Replacement Cylinder Clamp (All Aluminum Rail)6835-TOMM$13.86
37Tommy Gate 4188 - 19-Tooth Repair Sprocket with 3/4 Inch x 2 Inch Pin and KeeperTommy Gate 4188 - 19-Tooth Repair Sprocket with 3/4 Inch x 2 Inch Pin and Keeper4188-TOMM$78.12
38Tommy Gate 4189 - 25-Tooth Repair Sprocket with 3/4 Inch x 2 Inch Pin and KeeperTommy Gate 4189 - 25-Tooth Repair Sprocket with 3/4 Inch x 2 Inch Pin and Keeper4189-TOMM$114.03
39Tommy Gate 12609 - Replacement 1/4 Inch x 20 Inch Hydraulic HoseTommy Gate 12609 - Replacement 1/4 Inch x 20 Inch Hydraulic Hose12609-TOMM$69.30
40Tommy Gate 12611 - Replacement 90 Degree Elbow 9/16 x 7/16Tommy Gate 12611 - Replacement 90 Degree Elbow 9/16 x 7/1612611-TOMM$15.60
41Tommy Gate 13562 - 295 Pitch Replacement Roller Chain Above Bed Pass. Side(TX)Tommy Gate 13562 - 295 Pitch Replacement Roller Chain Above Bed Pass. Side(TX)13562-TOMM$357.53
42Tommy Gate 8030 - Replacement Roller Chain Attachment FittingTommy Gate 8030 - Replacement Roller Chain Attachment Fitting8030-TOMM$38.28
43Tommy Gate 13826 - 329 Pitch Replacement Roller Chain (85TX)Tommy Gate 13826 - 329 Pitch Replacement Roller Chain (85TX)13826-TOMM$396.90
43Tommy Gate 8044 - 335 Pitch Replacement Roller Chain Above Bed Driver's Side(95 and 89TX)Tommy Gate 8044 - 335 Pitch Replacement Roller Chain Above Bed Driver's Side(95 and 89TX)8044-TOMM$398.48
44Tommy Gate 7947 - Roller Chain Adjustment Screw - Clevis and PinTommy Gate 7947 - Roller Chain Adjustment Screw - Clevis and Pin7947-TOMM$46.94
46Tommy Gate 13563 - Replacement Alum. Roller Chain Cover(TX)Tommy Gate 13563 - Replacement Alum. Roller Chain Cover(TX)13563-TOMM$40.17
47Tommy Gate 998 - Replacement 150 Amp Manual Reset Circuit BreakerTommy Gate 998 - Replacement 150 Amp Manual Reset Circuit Breaker998-TOMM$89.63
48Tommy Gate 13564 - Replacement Alum AB Sprocket Assembly-R(TX)Tommy Gate 13564 - Replacement Alum AB Sprocket Assembly-R(TX)13564-TOMM$89.63
49Tommy Gate 13638 - Replacement Alum AB Sprocket Assembly-L(TX)Tommy Gate 13638 - Replacement Alum AB Sprocket Assembly-L(TX)13638-TOMM$89.63
54Tommy Gate 13639 - Replacement Alum Platform Self Close Arm Kit (TX)Tommy Gate 13639 - Replacement Alum Platform Self Close Arm Kit (TX)13639-TOMM$129.63
55Tommy Gate 8138 - Replacement Self-Close 2 Inch Roller KitTommy Gate 8138 - Replacement Self-Close 2 Inch Roller Kit8138-TOMM$21.42
56Tommy Gate 8068 - Repair Self-Close Arm Bushing Kit-Aluminum PlatformTommy Gate 8068 - Repair Self-Close Arm Bushing Kit-Aluminum Platform8068-TOMM$28.98
59Tommy Gate 922 - Replacement Extension Spring Rail (0.142 x 1.125 x 5.5 Inches)Tommy Gate 922 - Replacement Extension Spring Rail (0.142 x 1.125 x 5.5 Inches)922-TOMM$13.55
65Tommy Gate 13640 - (TX) Replacement Self-Close Safety Trip Bar (81-1/4'')Tommy Gate 13640 - (TX) Replacement Self-Close Safety Trip Bar (81-1/4'')13640-TOMM$119.87
65Tommy Gate 13641 - (TX) Replacement Safety Trip Bar 83-1/4'' (TA) (SPEC GATE ONLY)Tommy Gate 13641 - (TX) Replacement Safety Trip Bar 83-1/4'' (TA) (SPEC GATE ONLY)13641-TOMM$119.87
65Tommy Gate 13827 - Replacement Safety Trip Bar 79-1/4'' (85)Tommy Gate 13827 - Replacement Safety Trip Bar 79-1/4'' (85)13827-TOMM$119.87
66Tommy Gate 9645 - Release Solenoid External Assembly with ConnectorTommy Gate 9645 - Release Solenoid External Assembly with Connector9645-TOMM$146.01
67Tommy Gate 1110 - 2 Inch Cylinder Repair Kit (Rail)Tommy Gate 1110 - 2 Inch Cylinder Repair Kit (Rail)1110-TOMM$234.68
68Tommy Gate 12626 - Replacement UHMW Poly. Rail Plate Wear LatchTommy Gate 12626 - Replacement UHMW Poly. Rail Plate Wear Latch12626-TOMM$40.01
95Tommy Gate 11805 - Replacement Self-Close Handle GripTommy Gate 11805 - Replacement Self-Close Handle Grip11805-TOMM$12.45
96Tommy Gate 921 - Replacement Alum Platform Triangle DeadmanTommy Gate 921 - Replacement Alum Platform Triangle Deadman921-TOMM$9.45
97Tommy Gate 13599 - Replacement Latch Flipper Wear PlateTommy Gate 13599 - Replacement Latch Flipper Wear Plate13599-TOMM$27.26

LIFTGATE PARTS ORDERED WITHOUT PROVIDING YOUR LIFTGATE MODEL/SERIAL NUMBERS ARE NOT ELIGIBLE FOR RETURN.

PLEASE NOTE THAT THE PRICES BELOW ARE FOR A SINGLE ITEM. THE QTY COLUMN ON THE DIAGRAM SHOWS THE TOTAL NUMBER YOU WILL NEED FOR A COMPLETE ASSEMBLY.

RTC Model Railgates have been designed specifically for “walk in” step vans and incorporate a roller-based drive system to ensure sturdy, dependable performance through extensive cycling. Lightweight, corrosion resistant, low maintenance, and operator safe, fleet managers and drivers alike appreciate the ease and convenience of these specially constructed lifts.

For use with Step Vans.
