Maxon TE-33 (Jan 2018 - Present) Dual Step Kits Diagram From ITEParts.com

ID	Title	SKU	Price
2	Maxon 281038-01 - Vertical Pump Cover	281038-01-MAXO	$47.36
3	Maxon 900009-8 - Screw Cap 5/16-18 X 2 Inch GR8 ZC	900009-8-MAXO	$0.60
4	Maxon 281062-02 - Flat Holder 1.56 LG	281062-02-MAXO	$6.17
5	Maxon 901001 - Nut - Nylon - 5/16-18 Zinc	901001-MAXO	$0.18
6	Maxon 902013-10 - Washer Flat 5/16 Inch SAE ZC	902013-10-MAXO	$0.18
7	Maxon 902011-4 - Washer Lock 3/8 X .094 ZC	902011-4-MAXO	$0.15
8	Maxon 900014-4 - Hex Cap Screw - .38-16 X 1 G8 ZC	900014-4-MAXO	$0.71
9	Maxon 900014-5 - Screw Hex Cap - .38-16 X 1.25 G8 ZC	900014-5-MAXO	$0.72
10	Maxon 902013-11 - Flat Washer 3/8 Inch ZC	902013-11-MAXO	$0.18
11	Maxon 900009-3 - Hex Bolt 5/16-18 X 3/4 - GR8 ZC	900009-3-MAXO	$0.38
12	Maxon 269191-03 - Cable Assembly Ground 2 GA X 22 Inch LG	269191-03-MAXO	$29.00
13	Maxon 093203-10 - Neoprene Bulb - Trim Seal - 59.5 Inch LG	093203-10-MAXO	$46.20
14	Maxon 266428-08 - Grommet 1 DIAPH .19/.31 Holes	266428-08-MAXO	$2.88
15	Maxon 266428-02 - Grommet 1.0 DIAPH .25 Hole	266428-02-MAXO	$3.42

INCLUDE MODEL AND SERIAL NUMBER WHEN ORDERING! TO HELP YOU IDENTIFY THE DATE RANGE:

LOCATE YOUR SERIAL PLATE on your Liftgate.
LOOK FOR THE ‘SERIAL #’ FIELD and identify the first four digits.
IF your Liftgate was manufactured BEFORE JUNE 2014, your plate will show the Month then the Year.
IF your Liftgate was manufactured AFTER JUNE 2014, your plate will show the Year then the Month.
