Buyers Products HV211AAG3ED0 – VALVE 4W SPRING CTR 4 WAY SPRING CENTER

General Specifications
• Number of Spools: 2
• Rated Working Pressure 2500 PSI (172 bar)
• Max. Shock and Surge Pressure 4000 PSI (276 bar)
• Rated Flow Capacity 30 GPM (114 l/m)
• Max. Spool Leakage (1000 PSI) 16 cc/min
• Mounting, Any Position 3 Mounting Holes for 3/8″ Bolts
• Weight 2 Spools: 21 lbs.
VH1 Handle Sold Separately
Standard Features
• Integral load holding check valves (prevents reverse flow through valve when shifting)
• Integral differential poppet type relief valve, adjustable (set @ 2000 PSI, 10 GPM)
• Balanced, select-fit spools (provide minimum leakage, smooth operation)
• External spool seals (permit easy replacement, reduced maintenance cost)
• 3/4″ SAE inlet and outlet ports; 1/2″ or 3/4″ SAE work ports
