Maxon BMRSD (Sep 2013 - Dec 2015) Dual Pump Assembly Diagram (2 OF 2) From ITEParts.com

ID	Title	SKU	Price
1	Maxon 902013-14 - Washer Flat 9/16 Inch SAE ZC	902013-14-MAXO	$0.48
2	Maxon 902011-7 - Washer Lock .563 .141 THK	902011-7-MAXO	$0.26
3	Maxon 900033-6 - Screw Cap .5-20 X 2.25 Inch GR8 ZC	900033-6-MAXO	$1.77
4	Maxon 901011-10 - Nut Hex Head .500-20 UNF-2B	901011-10-MAXO	$0.44
5	Maxon 227722-01 - Rod L-Shape .31 X 11.5 Inch BAT HLDN	227722-01-MAXO	$6.23
6	Maxon 250479 - Bracket Battery X 15-3/8 Inch	250479-MAXO	$19.58
7	Maxon 902013-10 - Washer Flat 5/16 Inch SAE ZC	902013-10-MAXO	$0.18
8	Maxon 901005 - Nut Hex 5/16-18 Inch GR8 ZC	901005-MAXO	$0.17
9	Maxon 902011-3 - Lock Washer 5/16 X 5/64 Inch G8 ZC	902011-3-MAXO	$0.11
10	Maxon 902013-09 - Washer 1/4 Inch Zinc - Same 030564	902013-09-MAXO	$0.11
12	Maxon 901000 - Nylon Nut 1/4-20 Inch Zinc	901000-MAXO	$0.15
15	Maxon 221736 - Circuit Breaker 150A MAN RESET	221736-MAXO	$94.17
16	Maxon 269526-01 - Box Modified with Holes	269526-01-MAXO	$393.00

INCLUDE MODEL AND SERIAL NUMBER WHEN ORDERING! TO HELP YOU IDENTIFY THE DATE RANGE:

LOCATE YOUR SERIAL PLATE on your Liftgate.
LOOK FOR THE ‘SERIAL #’ FIELD and identify the first four digits.
IF your Liftgate was manufactured BEFORE JUNE 2014, your plate will show the Month then the Year.
IF your Liftgate was manufactured AFTER JUNE 2014, your plate will show the Year then the Month.
